I. Introduction
Reactive grab scales are used for the metering of tower-type reactive grab cranes. Generally there are two types: one is suitable for the metering of small cranes below 5t, which places the special metering head at the head of the crane and the display instrument can be placed in the cab or other places, connected by wires in the middle, with high metering accuracy.
The other one is suitable for large double cable grab crane in port, there are high precision sensors and transmitters on each rope, the force of each rope is transmitted to the receiving instrument respectively, the instrument carries out computer processing and displays the printed data.
II. Working principle
The reactive grab scales are specially designed to be used in reactive grab cranes to monitor the measurement of bulk materials during loading and unloading, with a special measuring head placed at the head of the crane's lifting arm and a display and control instrument that can be placed in the cab or at a suitable position in the lower part of the crane (with glass window and locking instrument box) and are specially designed to overcome the violent shaking of the grab and the inaccurate measurement caused by the irregular amplitude operation of the crane arm, and to automatically complete It is a highly efficient, purely dynamic weighing system, with automatic printing of a list of each ship's cargo.
2017-03-28
I. Introduction
Reactive grab scales are used for the metering of tower-type reactive grab cranes. Generally there are two types: one is suitable for the metering of small cranes below 5t, which places the special metering head at the head of the crane and the display instrument can be placed in the cab or other places, connected by wires in the middle, with high metering accuracy.
The other one is suitable for large double cable grab crane in port, there are high precision sensors and transmitters on each rope, the force of each rope is transmitted to the receiving instrument respectively, the instrument carries out computer processing and displays the printed data.
II. Working principle
The reactive grab scales are specially designed to be used in reactive grab cranes to monitor the measurement of bulk materials during loading and unloading, with a special measuring head placed at the head of the crane's lifting arm and a display and control instrument that can be placed in the cab or at a suitable position in the lower part of the crane (with glass window and locking instrument box) and are specially designed to overcome the violent shaking of the grab and the inaccurate measurement caused by the irregular amplitude operation of the crane arm, and to automatically complete It is a highly efficient, purely dynamic weighing system, with automatic printing of a list of each ship's cargo.
2017-03-28
Working Principal
The reactive grab scales are specially designed to be used in reactive grab cranes to monitor the measurement of bulk materials during loading and unloading, with a special measuring head placed at the head of the crane's lifting arm and a display and control instrument that can be placed in the cab or at a suitable position in the lower part of the crane (with glass window and locking instrument box) and are specially designed to overcome the violent shaking of the grab and the inaccurate measurement caused by the irregular amplitude operation of the crane arm, and to automatically complete It is a highly efficient, purely dynamic weighing system, with automatic printing of a list of each ship's cargo.
2017-03-28
Working Principal
The reactive grab scales are specially designed to be used in reactive grab cranes to monitor the measurement of bulk materials during loading and unloading, with a special measuring head placed at the head of the crane's lifting arm and a display and control instrument that can be placed in the cab or at a suitable position in the lower part of the crane (with glass window and locking instrument box) and are specially designed to overcome the violent shaking of the grab and the inaccurate measurement caused by the irregular amplitude operation of the crane arm, and to automatically complete It is a highly efficient, purely dynamic weighing system, with automatic printing of a list of each ship's cargo.
2017-03-28
Technical parameters
Measuring range: 100KG-30,000KG
A/D conversion speed: 100 times
A/D conversion resolution: 1 million
Non-linearity:≤0.01%F□S□
Zero point temperature drift:≤υ0.1V/℃
Full scale temperature coefficient:5ppm/℃
Minimum resolution:υ0.1V/d
Sensor power supply bridge voltage: DC5V, up to 10 350 sensors
Radio frequency: 433MHZ with 32 frequency points optional
Wireless transmission distance: not less than 450M when no obstruction
Serial communication interface: RS-232C and 20MA current loop
Baud rate: 1200bps
Display standby time: ≤50h
Operating temperature:-30~+70°
Power supply:220V+-10% and with 6V4AH battery
Maximum power;60W
Transmission speed:1200BIT/S
Safety load:120%
2017-03-28
Technical parameters
Measuring range: 100KG-30,000KG
A/D conversion speed: 100 times
A/D conversion resolution: 1 million
Non-linearity:≤0.01%F□S□
Zero point temperature drift:≤υ0.1V/℃
Full scale temperature coefficient:5ppm/℃
Minimum resolution:υ0.1V/d
Sensor power supply bridge voltage: DC5V, up to 10 350 sensors
Radio frequency: 433MHZ with 32 frequency points optional
Wireless transmission distance: not less than 450M when no obstruction
Serial communication interface: RS-232C and 20MA current loop
Baud rate: 1200bps
Display standby time: ≤50h
Operating temperature:-30~+70°
Power supply:220V+-10% and with 6V4AH battery
Maximum power;60W
Transmission speed:1200BIT/S
Safety load:120%
