MODEL | TCF400×150 | TCF400×200 | TCF360×250 |
Inlet size (mm) | 150×100 | 250×150 | 250×200 |
Feeding granularity (mm) | ≤100 | ≤100 | ≤150 |
Discharging granularity (mm) | 0.2~6 | 0.2~6 | 3~13（Adjustable） |
Productivity (kg / h) | 400-800 | 600-850 | 600-1000 |
Spindle speed (rev / min) | 850 | 850 | 1100 |
Motor model / power (kw) | Y100L2-4/3 | Y100L2-4/3 | Y100L2-4/3 |
Machine weight (kg) | 150 | 200 | 300 |
